16m Fixed Boom 5t Electrical Telescopic Boom Crane
Main Features And Advantages
1.Easy maintenance at all situation
2.Self contained unit with integrated hydraulic power pack
3.Fail-safe brakes on all movements
4.Fully enclosed and equipped operator cabin with air condition
5.The variable speed hoist will automatically adjust to the highest possible speed for the appropriate load
6.Base on many year's design and fabrication experience of crane and other similar equipment
7.Suitable for all kinds of ships and low power consumption and high efficiency
8.Welded and high strength box boom for easy maintenance
9.With Many safety protection devices---hook up limiter and overload limiter, emergency stop button
General Arrangement
Specification
| SWL | 5T@6M |
| MAX WORKING RADIUS | 6m |
| MIN WORKING RADIUS | 2m |
| HOISTING SPEED | 0~12m/min |
| HOISTING HEIGHT | 15m |
| SLEWING SPEED | ~0.5r/min |
| SLEWING ANGLE | 360° |
| WORKING CONDITION | TRIM ≤2° HEEL ≤5° |
| ELEC-MOTOR POWER | Y160K-4-H |
| POWER | 4.5kw |
| Speed | 1475r/min |
| POWER RESOURCE | AC415V/50HZ |
| PROTECT CLASS | IP56 |
| INSUKATE CLASS | F |
| WORKING TYPE | S1 |
Package at OUCO workshop
FAQ:
Q:1. What's the information should I provide when inquiry?
A: More details or drawings, better.
A: Lift capacity B: span C: lift height D: power sourceor other specials you give us will be more appreciated.
Q:2. How many operating methods for my selection?
A: Standard operating methods:
A: pendent controller with push buttons .B: remote control with push buttons
C: cabin(space capsule seat) control with joystick. Choose any type as you like.
Q:3. Can this type work in hazardous environment?
A: Sure! We can customize for you, acid proof or explosion proof, no problem for that.
Q:4. Can you provide the serious lifting tools?
A: Sure, we can provide any lifting tools such as lift sling belt, lift clamp, grab, etc as your requirement!
Q:5. How can we install the crane?
A: Our senior engineer can guide the installation train your crew on vessel.
Q:6. Safety device
A: Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
